±0.5% · F1″ or 1 1/2″
MGI-250 1″ · Pulser
MGI-250 1 1/2″ · Pulser
Pulser for its in-line assembly, making easier the exact information of the fluid management and control systems.
Technical data:
- Flow (approx.):
- 10-250 l/min (diesel)
- 10-150 l/min (lubricant
- Viscosity: 2-2000 cSt
- Voltage: 28 VDC
- Max. power: 8 W
- Maximum current: 100 mA
- Accuracy: ±0.5%
- Maximum pressure: 45 bar
- Min./max. temperature with Reeds: -10ºC / +90ºC
- Two channels: 11 pulses per litre and channel
- Inlet / outlet connection: F1″ or 1 1/2″ BSP (flange)
- Housing and cover: Aluminium
Size and weight (approx.):
MGI-250 F1″
- Dim.: 159x100x141 mm (length x width x height)
- Weight: 2.3 kg
MGI-250 F1 1/2″
- Dim.: 183x100x141 mm (length x width x height)
- Weight: 2.5 kg
