Multi-fuel filtration with water control
> Filtration rating: 5 µm (FG-100 & FG-100G), 25 µm (FG-100BIO)
> Compatible with diesel, petrol, biodiesel, kerosene, AVGAS, JET A-1
> Water-repellent filtering paper with 93% water decanting efficiency
> Filtering capacity: 2 litres
> Flow rate: up to 105 litres per minute

Durable construction with smart design
> Inlet/Outlet: F1″ BSP flanges or threads
> Aluminium upper housing with transparent vessel
> Max working pressure: 5 bar
> Vessel breaking pressure: 8 bar
> Max working depressure: -0.5 bar

Fast, tool-assisted cartridge replacement
> Quick-change ring system with supplied filter key
> Supplied with: housing, filtering cartridge, and cartridge key
> Temperature range: -10 ºC to +50 ºC
> Box dimensions: 190 × 230 × 330 mm
> Gross weight: approx. 2.72 kg

The FG-100 is the all-in-one filtration solution for clean, water-free fuel transfer—built for operators who need efficiency, reliability, and versatility.
